Aquila multichannel: dimmable LED lamps for plants research and study of plants growth
Attachment
Aquila multichannel: dimmable LED lamps for plants research and study of plants growth

Aquila Multichannel is a compact, high-precision LED lamp ideal for plants research and experimental setups in institutions such as universities, CREA, and CNR. It supports the study of plants by enabling detailed growth tests on multiple species. Researchers can adjust both light intensity and LED light spectrum, allowing optimal conditions for controlled plants growth. Perfect for indoor vertical farming and plants shelves, each unit includes two independent channels. LEDs can be individually assigned to a channel during assembly. By connecting 2 or 3 lamps using the included clips, you can expand to 4 or 6 independent channels. These are powered via a supply compatible with dimmable LED lamps, controllable by app or 0–10 V systems.

Technical details

  • Power supply
    100 ÷ 305 Vac 50/60 Hz or 200 ÷ 480 Vac 50/60 Hz
    Universal power range

  • Power consumption
    25 ÷ 60 W

  • PAR photon flux output
    80 ÷ 200 μmol/s
    Excellent photon flux per second

  • PAR efficiency
    3.00 ÷ 3.40 μmol/J

  • Operating temperature
    0 ÷ 45 °C

  • Dimensions
    1000 ÷ 1500 x 32 x 32 mm

  • Humidity protection rating
    IP65
    High protection against water and dust

  • Weight
    680 g @ L=1.2 m

  • Protections
    Short circuit, overcurrent, overvoltage, overtemperature

  • Light output
    Custom spectrum based on requirements.
    2, 4, or 6 independent channels

  • Dimmer
    Optional
    Analog, digital, or via APP

  • Light intensity decline
    After 100.000 hours
