Maximum flexibility for advanced research on plants

Side View
Elettra multichannel: Dimmable LED lighting for plants research, study of plants growth
Detail
Elettra multichannel: Dimmable LED lighting for plants research, study of plants growth

Elettra Multichannel is a high-performance solution dedicated to plants research, enabling the study of plants through experimental growth tests. It allows precise control of both light intensity and LED light spectrum, helping researchers define optimal plants growth parameters. Ideal for plants shelves and indoor vertical farming, Elettra Multichannel supports up to 16 independent channels, including one for UV light. Each wavelength can be mapped to specific channels. Control is managed via just two wires using a 0–10 Vdc external device, or through Modbus RS485/TCP-IP protocols. WiFi and Bluetooth interfaces allow remote channel control via a dedicated app. This dimmable LED lighting solution is powered by a single supply that manages the lamp’s full power output efficiently.

Technical details
  • Power supply
    100 ÷ 305 Vac 50/60 Hz or 200 ÷ 480 Vac 50/60 Hz
    Universal power range
  • Power consumption
    300 ÷ 330 W

  • PAR photon flux output
    900 ÷ 1100 μmol/s
    Excellent photon flux per second

  • PAR efficiency
    3.00 ÷ 3.40 μmol/J
    Number of photons per second per Watt consumed

  • Operating temperature
    0 ÷ 45 °C

  • Dimensions
    690 x 180 x 130 mm

  • Humidity protection rating
    IP65
    High protection against water and dust

  • Weight
    5,5 Kg

  • Protections
    Short circuit, overcurrent, overvoltage, overtemperature
  • Light output
    Custom spectrum: up to 16 independent channels, including one dedicated to UV light

  • Interface
    RS485, WiFi, Bluetooth, Ethernet

  • Light intensity decline
    Maintains 90% after 100.000 hours
